Double Layer Unique Combination Forming Fabric for Paper Making - KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for

  • 1
  • 2

Pattern description : 8/16 Shed

Basis Weight (g/m²) : 850

CMD Yarns Top : 0.20mm, 0.27mm 22.6 /cm PET

Air Permeability : 360 CFM @ 125 Pa

Void Volume : 811 ml/m² (55.9%)

Caliper (mm) New : 1.450

Fiber Support Index : 79

Paper Side Open Area : /

CMD Yarns Bottom : 0.50mm 11.3 /cm PET/PA

Fiber Support Point : 170 /cm²

Drainage Index : 22.2

Caliper (mm) Critical : 0.970

Break Strength : ≥1100 N/cm

Structure : 2.5 Layer

Fabric Color : Light Green, Light Blue

MD Yarns Top : 0.27mm 40.0 /cm PET

MD Yarns Bottom : /

Brand Name : ATMC

MOQ : 1pc

Price : inquiry

Payment Terms : L/C,D/A,D/P,T/T

Packaging Details : Standard export ply-wood case

Elongation(50N/cm) : ≤0.40%

Contact Now

KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for Board and Packaging Papers
The KRAFT DRAFT DLA47816SM forming fabric features an innovative coarse-mesh, 8-over-16 shed double-layer construction. By integrating an additional cross-direction (CD) yarn, it delivers superior sheet support and formation stability. This weave maximizes drainage capacity, while its coarse, large-diameter wear-side weft yarns are engineered for exceptional abrasion resistance and extended operational life.
Key Features

  • Superior Sheet Support & Drainage: Coarse 8-shed paper side structure uniquely combines high fiber support with very high drainage capacity.

  • High Top Surface Open Area: The specific weave maximizes open area on the sheet side, directly contributing to rapid and efficient dewatering.

Product Parameters
Product Name Forming Fabric KRAFT DLA47816SM
Material Polyester monofilament
Function Paper Machine
Application Light GSM Kraft Paper, Wrapping Paper, etc.
Technical 1/1.5/2/2.5/3 layers forming fabric
Width Customized
Weight Customized
Fabric Color Customized
Product Images
Double Layer Unique Combination Forming Fabric for Paper Making - KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for Double Layer Unique Combination Forming Fabric for Paper Making - KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for
Top Side View Bottom Side View
Application
Wrapping and Packing Papers, Board Grades.
Double Layer Unique Combination Forming Fabric for Paper Making - KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for Double Layer Unique Combination Forming Fabric for Paper Making - KRAFT DLA47816SM-380CFM Delivers High Fiber Support & Extreme Drainage, Ideal for
