2.5 Layer Polyester Pulp Forming Fabric for Fourdrinier Machines

Name: 25 Layer Polyester Pulp Forming Fabric for Fourdrinier Machines
Brand: ATMC
Price: 1 USD

Buy cheap 2.5 Layer Polyester Pulp Forming Fabric for Fourdrinier Machines product

Pattern description : 8 Shed

Basis Weight (g/m²) : 1100

CMD Yarns Top : 0.25mm, 0.50mm 14.0 /cm PET

Air Permeability : 650 CFM @ 125 Pa

Void Volume : 1143 ml/m² (58.0%)

Brand Name : ATMC

Caliper (mm) New : 1.970

Fiber Support Index : 48

Paper Side Open Area : /

CMD Yarns Bottom : 0.60mm 7.0 /cm PET

Fiber Support Point : 60 /cm²

Drainage Index : 20.1

Caliper (mm) Critical : /

Break Strength : ≥2000 N/cm

MOQ : 1 pc

Price : inquiry

Payment Terms : L/C,D/A,D/P,T/T

Packaging Details : Standard export ply-wood case

Structure : 2.5 Layer

Fabric Color : Light Green, Light Blue

MD Yarns Top : 0.45mm 23.0 /cm PET

MD Yarns Bottom : /

Elongation(50N/cm) : ≤0.65%

Contact Now

PULP DLA23808SH

The PULP DLA23808SH is a strong eignt sheddouble layer containing an additional cross direction(CD) yarn for improved pulp web support. This weavepattern provides smooth surface and excellentdrainage capacity. This design with coarse and largediameter wear side weft yarn for excellent structurestability and life potential.

· Seam Type: Joined Endless

· Width: Up to 10 M

· Applications: Newsprint Paper, Specialty Papers

Product Specifications

Attribute	Value
Structure	/
Pattern Description	/

Features and benefits:

1. 8-shed extra support shute top side offers aunique combination of high web support and veryhigh drainage capacity as a result of the high topsurface open area.

2. The pulp web gets sufficient support and does notget pressed inside the fabric structure due tosmooth-surface.

2.5 Layer Polyester Pulp Forming Fabric for Fourdrinier Machines

Top side Wear Side

Application

Dewatering of stocks from hard and softwood, mechanical or chemical pulp, bleached or unbleached.
