KRAFT DLA41816SC-450CFM Double Layer Weave, Unique Fiber Support & Drainage Combination, Excellent Wear Resistance

Optimizing the papermaking process, the KRAFT DLA41816SC features a unique coarse-mesh, double-layer architecture (8-shed over 16-shed). The integration of a supplementary CD yarn provides critical enhancement to sheet support. This configuration ensures excellent drainage capacity, while the implementation of large-diameter wear-side yarns directly contributes to remarkable fabric longevity, ideal for continuous high-output production.

Key Features

Extended Operational Lifespan: The durable wear-side yarn design directly contributes to a substantial increase in overall fabric life and service potential.

High Load & Ridge Resistance: Double MD yarn lock construction on the wear side provides exceptional resistance to high machine-direction loads and prevents CD ridging.

Product Parameters

Product Name	Forming Fabric KRAFT DLA41816SC
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weight	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Wrapping and Packing Papers, Board Grades.
