Single Layer Forming Fabric KRAFT SL2105L - with 1x4 Five Shed Weave Pattern for Good Wear Potential in Kraft Paper

Name: Single Layer Forming Fabric KRAFT SL2105L with 1x4 Five Shed Weave Pattern for Good Wear Potential in Kraft Paper
Brand: ATMC
Price: 1 USD

Buy cheap Single Layer Forming Fabric KRAFT SL2105L - with 1x4 Five Shed Weave Pattern for Good Wear Potential in Kraft Paper product

Brand Name : ATMC

MOQ : 1pc

Price : inquiry

Payment Terms : L/C,D/A,D/P,T/T

Packaging Details : Standard export ply-wood case

Caliper (mm) Critical : /

Break Strength : ≥850 N/cm

Structure : Single Layer

Fabric Color : Light Green

Pattern description : 5 Shed

Basis Weight (g/m²) : /

CMD Yarns Top : /

Air Permeability : 475CFM, 7500m³ /m²h

Void Volume : /

Caliper (mm) New : 0.88

Fiber Support Index : 64

Paper Side Open Area : 13.4%

CMD Yarns Bottom : /

Fiber Support Point : /

Drainage Index : 6.7

MD Yarns Top : /

Elongation(50N/cm) : ≤0.50%

MD Yarns Bottom : /

Contact Now

Forming Fabric KRAFT SL2105L - Single Layer Design for Kraft Paper with Good Wear Potential and Stability

The KRAFT SL2105L is a coarse mesh one up four down single layer fabric design. This unique structure provides increased internal void volume over standard four shed designs with good fiber support, more drainage capacity and easy sheet release.

Key Features

1x4 five shed weave pattern
Increased void volume over four shed design

Product Parameters

Product Name	Forming Fabric KRAFT SL2105L
Material	Polyester monofilament
Function	Paper Machine
Application	Light GSM Kraft Paper, Wrapping Paper, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images


Top Side View	Bottom Side View

Application

Single Layer Forming Fabric KRAFT SL2105L - with 1x4 Five Shed Weave Pattern for Good Wear Potential in Kraft Paper
