1.5-Layer KRAFT SLA24510C Forming Fabric with Five Over Ten Shed Weave Pattern for High Drainage and Long Life on Paper Machines

Product Categories
Anhui Towin Machinery Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

1.5-Layer KRAFT SLA24510C Forming Fabric with Five Over Ten Shed Weave Pattern for High Drainage and Long Life on Paper Machines

  • 1
  • 2

Pattern description : 5/10 Shed

Basis Weight (g/m²) : 620

CMD Yarns Top : 0.27mm 15.5 /cm PET/PA

Air Permeability : 520 CFM @ 125 Pa

Void Volume : 674 ml/m² (59.1%)

Caliper (mm) New : 1.140

Fiber Support Index : 79

Paper Side Open Area : 21.4%

CMD Yarns Bottom : 0.45mm 15.5 /cm PET/PA

Fiber Support Point : /

Drainage Index : 24.7

Caliper (mm) Critical : 0.720

Break Strength : ≥800 N/cm

Structure : 1.5 Layer

Fabric Color : Light Green, Light Blue, White

Brand Name : ATMC

MOQ : 1pc

Price : inquiry

Payment Terms : L/C,D/A,D/P,T/T

Packaging Details : Standard export ply-wood case

MD Yarns Top : 0.25mm 24.0 /cm PET

MD Yarns Bottom : /

Elongation(50N/cm) : ≤0.50%

Contact Now

KRAFT SLA24510C Forming Fabric - 10 Shed 1.5 Layer Design for High Drainage & Long Life on Fourdrinier & Multi-Wire Machines
The KRAFT SLA24510C is a coarse mesh ten shed 1.5 layer forming fabric with increased internal void volume and superior drainage capacity. Its ten-shed design is suitable for Fourdrinier and Multi-wire machines across various paper grades, particularly where extended forming fabric life is prioritized over single-layer alternatives.
Key Features
  • Five over ten shed weave pattern
  • Increased internal void volume compared to eight shed designs
Product Parameters
Product Name Forming Fabric KRAFT SLA24510C
Material Polyester monofilament
Function Paper Machine
Application Light GSM Kraft Paper, Wrapping Paper, etc.
Technical 1/1.5/2/2.5/3 layers forming fabric
Width Customized
Weight Customized
Fabric Color Customized
Product Images
1.5-Layer KRAFT SLA24510C Forming Fabric with Five Over Ten Shed Weave Pattern for High Drainage and Long Life on Paper Machines
Top Side View
1.5-Layer KRAFT SLA24510C Forming Fabric with Five Over Ten Shed Weave Pattern for High Drainage and Long Life on Paper Machines
Bottom Side View
Application
Suitable for Wrapping and Packing Papers, Board Grades.
1.5-Layer KRAFT SLA24510C Forming Fabric with Five Over Ten Shed Weave Pattern for High Drainage and Long Life on Paper Machines
1.5-Layer KRAFT SLA24510C Forming Fabric with Five Over Ten Shed Weave Pattern for High Drainage and Long Life on Paper Machines
