SSB Triple Layer Paper Machine Forming Fabric KRAFT SSB60210WM55-400CFM: Two Shed / Ten Shed Shute Binding with 3:2 CD Ratio for Exceptional Stability

  • 1
  • 2

Caliper (mm) Critical : 0.870

Break Strength : ≥900 N/cm

Price : inquiry

Structure : SSB Triple Layer

Fabric Color : Light Green, Light Blue

Pattern description : 2/10 Shed

Basis Weight (g/m²) : 710

CMD Yarns Top : 0.17mm 34.8 /cm PET/PA

Air Permeability : 400 CFM @ 125 Pa

Void Volume : 716 ml/m²(51.3%)

Payment Terms : L/C,D/A,D/P,T/T

MOQ : 1pc

Caliper (mm) New : 1.250

Fiber Support Index : 130

Paper Side Open Area : 32.1%

Brand Name : ATMC

CMD Yarns Bottom : 0.40mm 17.4 /cm PET/PA

Fiber Support Point : 650 /cm²

Drainage Index : 26.4

MD Yarns Top : 0.17mm 25.0 /cm PET

MD Yarns Bottom : 0.25mm 25.0 /cm PET

Packaging Details : Standard export ply-wood case

Elongation(50N/cm) : ≤0.40%

Contact Now

SSB Triple Layer Paper Machine Forming Fabric KRAFT SSB60210WM55-400CFM: Two Shed / Ten Shed Shute Binding with 3:2 CD Ratio for Exceptional Stability

Designed for demanding paper making environments, KRAFT SSB60210WM features a two‑shed over ten‑shed shute binding as a standard SSB triple layer fabric. The fine paper side ensures even surface profiles and excellent fiber support, resulting in uniform formation. Its wear side incorporates an open, long‑float structure with a 3:2 CD shute ratio, enabling the use of medium and coarse CD yarns for extended life potential. Two MD thread systems deliver a stable construction with high CD stability. The open weave design facilitates high water removal rates and simplifies shower cleaning. This forming fabric offers outstanding durability, drainage, and sheet support.


Key Features
  • Dual MD thread systems ensure rigid fabric structure.
  • High CD stability reduces lateral movement during operation.
  • Medium CD yarns combined with long float improve wear resistance.


Product Parameters
Product Name Forming Fabric KRAFT SSB60210WM
Material Polyester monofilament
Function Paper Machine
Application Light GSM Kraft Paper, Wrapping Paper, etc.
Technical SSB Triple Layer forming fabric
Width Customized
Weight Customized
Fabric Color Customized
Product Images
SSB Triple Layer Paper Machine Forming Fabric KRAFT SSB60210WM55-400CFM: Two Shed / Ten Shed Shute Binding with 3:2 CD Ratio for Exceptional Stability SSB Triple Layer Paper Machine Forming Fabric KRAFT SSB60210WM55-400CFM: Two Shed / Ten Shed Shute Binding with 3:2 CD Ratio for Exceptional Stability
Top Side View Bottom Side View
Application
Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
SSB Triple Layer Paper Machine Forming Fabric KRAFT SSB60210WM55-400CFM: Two Shed / Ten Shed Shute Binding with 3:2 CD Ratio for Exceptional Stability SSB Triple Layer Paper Machine Forming Fabric KRAFT SSB60210WM55-400CFM: Two Shed / Ten Shed Shute Binding with 3:2 CD Ratio for Exceptional Stability
